Four-way Shuttle Cart
Four direction moving, layer changing on vertical and intelligent control
The pallet four-way shuttle is an intelligent device used for pallet cargo handling. It can achieve both vertical and horizontal travel, and can reach any position in the warehouse. The horizontal movement and retrieval of goods in the shelf is completed by only one four-way shuttle car. The level of system automation is greatly improved through hoisting. It is a new generation of intelligent handling equipment for pallet-type dense storage solutions.
Four Way Radio Shuttle Cart · Warehouse Storage Rack · Made In China
Product Advantage
——
- The four-way shuttle is an intelligent handling device capable of both vertical and horizontal traveling.
- The four-way shuttle is highly flexible, which can freely change the operation aisle. In addition, it is possible to adjust the system capacity by adding or reducing the number of shuttles. When necessary, a shuttle fleet may be established to respond to the system peak, thus solving the bottleneck of entry and exit operations.
- Four-way shuttles are interchangeable. When a shuttle or lift fails, other shuttles or lifts can be dispatched by the dispatching system for completing the operation without affecting the system capacity.
- The four-way shuttle is not only suitable for low-flow and high-density storage, but also suitable for high-flow and high-density storage. It can maximize the efficiency, cost and utilization of resources.
- Can drive in four directions, operate efficiently and flexibly across the roadway, without space restrictions, make full use of space;
- Connect to the control system through a wireless network, and can go to any cargo location in cooperation with the hoist;
- The four-way shuttle cart system is modular and standardized to realize discrete handling;
- Flexible layout and high storage density;
- Cooperate with patented track, the system cost is low;
Technical Specification
| Model | Load | Running speed | pallet size (mm) | Operating temperature | powered by | Battery performance | Equipment weight |
| Standard model | Max1.5T | 1.4m/s | width:1200-1600 depth:800-1200 | 0～45℃ | 72V/32AH | Lithium iron phosphate battery,Endurance7-9H | 350kg |
| Increase model | Max2T | 1.2m/s | width:2200 depth:2200 | 0～45℃ | 48V/40AH | Lithium iron phosphate battery,Endurance6-8H | 580kg |
Four Way Radio Shuttle Cart · Warehouse Storage Rack · Made In China
Four-Way Shuttle Cart For Cold Storage
—
The four-way shuttle for cold storage is a special handling and transportation intelligent storage equipment for cold warehouse. It can safely and stably store and distribute goods in the low temperature.
Advcantages of four-way shuttle for cold storage
- Using low-temperature batteries to ensure normal driving in the cold storage;
- Laminating the circuit board;
- The hydraulic system uses low-temperature hydraulic oil to ensure that the hydraulic pressure can run normally at low temperatures
Technical Specification
| Model | Load | Running speed | pallet size (mm) | Operating temperature | powered by | Battery performance | Equipment weight |
| Cold storage model | Max1.5T | 1.0m/s | width: 1200-1600 depth: 800-1200 | -25℃～0℃ | 72V/35AH | Lithium iron phosphate battery; Endurance5-6H | 450kg |
| Max1.2T | 1.2m/s |
Four Way Radio Shuttle Cart · Warehouse Storage Rack · Made In China
Four-Way Shuttle Cart For Explosion Proof Warehouse
—
CASE
—
Four Way Radio Shuttle Cart · Warehouse Storage Rack · Made In China
Production Scenarios
——
Four Way Radio Shuttle Cart · Warehouse Storage Rack · Made In China
Ensure the quality of Huayide racking products
—
| 1 | The raw material of the shelf is customized from China's large steel group of high quality carbon steel, durable and strong, to ensure the quality of the product from the source. |
| 2 | The shelf welding adopts dioxygen protection welding, the welding joint has good cracking resistance, small welding deformation, beautiful forming, and does not need slag cleaning. |
| 3 | Each column and beam of the shelf are designed by professional personnel with professional technology and cut by professional equipment, so as to ensure the accurate size of the shelf. |
| 4 | Professional spray before treatment, oil removal, rust removal, phosphating, powder, and then in high temperature oven baking molding, wear-resistant, rust proof. |
Four Way Radio Shuttle Cart · Warehouse Storage Rack · Made In China
